Depth : 28'
Height : 17'
Width : 40'
First Floor: 1130 sq/ft height 8'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2"x4"
Walk In Pantry Cabinet Pantry
3rd BR Closet:
13 sq/ft width 2' 2" x depth 6' 2"
1680 sq/ft width 28' x depth 60'
1680 sq/ft width 60' x depth 28'
120 sq/ft width 12' x depth 10'
Bedroom 2 Closet:
19 sq/ft width 3' 1" x depth 6' 4"
90 sq/ft width 9' x depth 10'
Bedroom 3 Closet:
19 sq/ft width 3' 1" x depth 6' 4"
192 sq/ft width 16' x depth 12'
419 sq/ft width 19' 8" x depth 21' 4"
46 sq/ft width 3' 1" x depth 15'
width 5' x depth 7' 10"
209 sq/ft width 15' 4" x depth 13' 8"
202 sq/ft width 15' 2" x depth 13' 4"
width 7' 8" x depth 5'
156 sq/ft width 12' x depth 13'
12 sq/ft width 2' 2" x depth 5' 10"
Porch - Front:
72 sq/ft width 4' x depth 18'
