Key Specs


1270
sq ft

2
Beds

2
Baths

1
Floors

0
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing.

Need a quote fast? Call us at 1-800-528-8070.

Floor Plans


Floor Plan - Main Floor Plan
Country Floor Plan - Main Floor Plan Plan #140-164

Full Specs & Features


Dimension
Depth : 42'
Height : 23'
Width : 46'
Area
First Floor: 1270 sq/ft height 10'
Roof
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Bedroom Features
Walk In Closet
Fireplace
Formal Dining Room
Kitchen Features
Kitchenette Wet Bar
Breakfast Nook
Outdoor Spaces
Covered Front Porch

What's Included In This Plan Set


  • Cover page
  • Elevations set to 3/16" scale
  • Dimensioned Floor plans set to 3/16" scale
  • Roof plan: Overhead plan shows peaks, valleys and roof pitch
  • Building Sections Interior Elevations: Cabinet and millwork details.
  • Electrical floor plan layout
  • Foundation plan
  • General notes and details.
