PLAN 17-2480
Photographs may show modified designs.
Get Personalized Help
Key Specs
2555
sq ft
5
Beds
4
Baths
2
Floors
2
Garages
WOW!
Cost to Build Reports
are Only $4.99
with Code CTB2023 (limit 1)
with Code CTB2023 (limit 1)
This report will provide you cost estimates based on location and building materials.
Construction Engineering Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
Get the Guide
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-528-8070
Phone: 1-800-528-8070
Hours: Mon - Fri 9:00 - 8:30 (EDT)
See our Terms & Conditions and Privacy Policy.
PLAN 17-2480
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
This elegantly simple Country style plan celebrates outdoor living with generous 10 foot-deep covered porches at the front and rear, as well as an outdoor grilling kitchen off the back veranda. Shed dormer windows brighten the two story great room -- with balcony and loft -- at the center of the design. The master suite is at one end of the house and the children's bedrooms are at the other. A separate structure to one side contains the garage with a guest suite on the upper level. There is an optional outdoor living area with its own outdoor fireplace.
Floor Plans
Floor Plan - Upper Floor
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 96'
Height : 28'
Width : 113'
Area
Bonus : 509 sq/ft
Garage : 838 sq/ft
Main Floor : 2049 sq/ft
Porch : 1408 sq/ft
Upper Floor : 506 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 10:12
Secondary Pitch : 5:12
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Garage Features
Detached Garage
Front Entry Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Outdoor Kitchen Grill
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
