PLAN 17-2466
Photographs may show modified designs.
Get Personalized Help
Key Specs
4212
sq ft
2
Beds
2
Baths
2
Floors
0
Garages
WOW!
Cost to Build Reports
are Only $4.99
with Code CTB2023 (limit 1)
with Code CTB2023 (limit 1)
This report will provide you cost estimates based on location and building materials.
Construction Engineering Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
Get the Guide
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-528-8070
Phone: 1-800-528-8070
Hours: Mon - Fri 9:00 - 8:30 (EDT)
See our Terms & Conditions and Privacy Policy.
PLAN 17-2466
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
This multi-family 4-plex has 548 square feet on the 1st floor and 505 on the 2nd. Featuring a great room, kitchen with a bar and a full bathroom on the 1st floor. The 2nd floor has 2 bedrooms and a full bathroom.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 32'
Height : 29'
Width : 72'
Area
Main Floor : 548 sq/ft
Upper Floor : 505 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 7:12
Roof Load : 45
Exterior Wall Framing
Framing : 2"x4"
Bedroom Features
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Great Room Living Room
Main Floor Laundry
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
