Plan Description

Each of the 3 units in this Modern Deco design building is 2330 sf with 3 bedrooms and 3.5 baths. The building is designed with an ICF exterior wall system providing a minimum R-30 insulation rating. Attached to the exterior wall face is a prefab aluminum panel and a prefab stone covered panel, providing a weather resistant superior insulated wall. All windows are insulated, Low-E units.

Floor Plans

Floor Plan - Main Floor

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 47' 3"

Height : 40' 9"

Width : 66' 3"

Area

Basement : 1500 sq/ft

Decks : 119 sq/ft

Garage : 600 sq/ft

Lower Floor : 2158 sq/ft

Main Floor : 2158 sq/ft

Upper Floor : 2158 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Roof Framing : WD. TRUSS

Roof Type : FLAT TRUSS

Exterior Wall Framing

Exterior Wall Finish : PREFAB METAL & STONE PANEL

Framing : ICF

Insulation : R-30

Bedroom Features

Main Floor Bedrooms

Walk In Closet

Kitchen Features

Eating Bar

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room

Main Floor Laundry

Garage Features

Garage Under

Oversized Garage

Rear Entry Garage

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Grill Deck Sundeck

Economical To Build

Energy Efficient Features

Energy Efficient Design

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
