This is a 6 unit, 1840 s.f. each apartment building offering an open kitchen plan-living area, 3 bedrooms, 2 1/2 baths. private outdoor deck plus in-unit laundry and utility rooms. The building construction is designed to maximize energy efficiency with ICF exterior walls, energy efficient, low-E windows and thermally designed roofing insulation.

Floor Plans

Floor Plan - Main Floor Plan
Contemporary Floor Plan - Main Floor Plan Plan #535-14

Full Specs & Features

Depth : 44' 5"
Height : 37' 3"
Width : 111' 8"
Decks : 750 sq/ft
Garage : 2600 sq/ft
Lower Floor : 3680 sq/ft
Main Floor : 3680 sq/ft
Porch : 1770 sq/ft
Storage : 1080 sq/ft
Upper Floor : 3680 sq/ft
Garage Ceiling : 8'
Main Ceiling : 9'
Roof Framing : WD. TRUSS
Roof Type : FLAT TRUSS
Exterior Wall Framing
Insulation : ICF, R30
Exterior Wall Finish : MASONRY/WOOD SIDING
Framing : ICF
Additional Room Features
Great Room Living Room
Main Floor Laundry
Storage Area
Garage Features
Garage Under
Rear Entry Garage
Outdoor Spaces
Economical To Build
Energy Efficient Features
Energy Efficient Design

What's Included In This Plan Set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
