Depth : 52'
Height : 22'
Width : 91' 8"
First Floor: 2739 sq/ft height 8'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Additional Room Features
Side Entry Garage
Suited For Corner Lot
Suited For View Lot
28 sq/ft width 5' 9" x depth 5'
42 sq/ft width 8' 6" x depth 5'
64 sq/ft width 6' x depth 10' 9"
42 sq/ft width 5' x depth 8' 6"
266 sq/ft width 16' x depth 16' 8"
61 sq/ft width 6' 4" x depth 9' 8"
23 sq/ft width 4' x depth 5' 9"
