PLAN 76-120
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.Plan Description
Full Specs & Features
Height : 20'
Width : 58'
Roof Framing : Truss
Roof Type : Tile
Framing : Block
Formal Living Room / Parlor
Main Floor Master Bedroom
Sunroom
3rd BR Closet:
16 sq/ft width 2' x depth 8'
Bathroom 2:
48 sq/ft width 6' x depth 8'
Bedroom 2:
132 sq/ft width 12' x depth 11'
Bedroom 2 Closet:
16 sq/ft width 2' x depth 8'
Bedroom 3:
156 sq/ft width 13' x depth 12'
Bedroom 3 Closet:
16 sq/ft width 2' x depth 8'
Breakfast Room:
60 sq/ft width 6' x depth 10'
Dining Room:
140 sq/ft width 14' x depth 10'
Foyer:
36 sq/ft width 6' x depth 6'
Garage:
462 sq/ft width 22' x depth 21'
Gathering Room:
300 sq/ft width 15' x depth 20'
Kitchen:
130 sq/ft width 13' x depth 10'
Living Room:
240 sq/ft width 16' x depth 15'
Master Bathroom:
175 sq/ft width 14' x depth 12' 6"
Master Bedroom:
238 sq/ft width 14' x depth 17'
Master Closet:
72 sq/ft width 9' x depth 8'
Porch - Rear:
168 sq/ft width 14' x depth 12'
Utility Room:
63 sq/ft width 9' x depth 7'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Reproducible Set : $794.75 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
PDF Set : $998.75 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
5 Copy Set : $1211.25 |
5 printed plan sets mailed to you. |
CAD Set : $1253.75 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Framing
Block: $0.00 |
Block |
Additional Options
Additional Construction Sets : $102.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design : $85.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
