PLAN 417-665

Key Specs

3680
sq ft

3
Beds

3.5
Baths

2
Floors

3
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.

Modify This Plan

Plan Description

Not many designs can compare with this one-of-a-kind plan. You enter the raised foyer and gaze through two story windows in the living room and look up to see the bridge to the second floor bedroom wing. Look right and you have a commanding view of the formal dining room with its built-in server and coffered ceiling. Look left and a stair case leads to a landing, where a niche makes the double door entry to the library at mid-level, then acsends further to the second floor. Descending a few steps to the main level of this home brings you into the formal living spaces, where the living room has a gently curved wall of windows and its two story ceiling is coffered in box pattern. Just to the left of the living room and around the corner is another series of staris which lead to a delightful and secluded powder room with a thorughtful niche besides the toilet. Double doors lead to the master suite, large enough for sleeping and sitting areas.

Floor Plans

Floor Plan - Main Floor

Reverse

House Plan Design - Mediterranean Floor Plan - Main Floor Plan #417-665

BUILDER Advantage Program

PRO BUILDERS:

Join the club and save 5% on your first order plus exclusive discounts and more.

JOIN FOR FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

House Plan Design - Mediterranean Floor Plan - Upper Floor Plan #417-665

Full Specs & Features

Dimension

Depth : 76' 2"
Height : 32'
Width : 73' 8"

Area

Bonus: 300 sq/ft
First Floor: 2285 sq/ft height 10'
Second Floor: 1395 sq/ft

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick/Stucco
Framing : Wood - 2x6

Bedroom Features

Fireplace
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Master Sitting Area
Unfinished Future Space

Garage Features

Side Entry Garage

Outdoor Spaces

Balcony
Courtyard
Deck

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
