Plan Description

Decorative stucco touches, an impressive entry and muntin windows grace the exterior of this home. Step inside and you will find that the open living space makes this compact home appear larger than it actually is. The living room flows easily into the dining room both boast volume ceilings. The galley kitchen looks over to the dining room, making it perfect for serving guests. A patio or optional screened porch is accessed from the dining area. The master bath is located to the rear of the plan, away from street traffic, and sports a full bath. Bedrooms 2 and 3 share a full bath.

Floor Plans

Floor Plan - Main Floor

Reverse

Builder Advantage Program

PRO BUILDERS:

Join the club and save 5% on your first order plus exclusive discounts and more.

JOIN FOR FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 60'
Height : 15'
Width : 30'

Area

First Floor: 1118 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Stucco
Framing : Block

Bedroom Features

Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom

Kitchen Features

Walk In Pantry Cabinet Pantry

Additional Room Features

Storage Area
Sunroom

Outdoor Spaces

Courtyard
Screened Porch

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

» See important information before purchasing.

Questions? Call 1-800-528-8070

Plan Set

PDF Set : $722.50	PDF plan sets are best for fast electronic delivery and inexpensive local printing.
5 Copy Set : $892.50	5 printed plan sets mailed to you.
5 Copy and PDF Set : $1020.00	5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Single Build : $1445.00	For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Study Set : $425.00	One electronic set for bidding purposes only. Not a legal building set for construction.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Block:
$0.00

Block

Additional Options

Additional Construction Sets : $42.50	Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design : $85.00	Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide : $33.15	Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design : $85.00	Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets : $25.50	A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
