PLAN 417-761

Photographs may show modified designs.

House Plan Design - Mediterranean Exterior - Front Elevation Plan #417-761

House Plan Design - Mediterranean Exterior - Rear Elevation Plan #417-761

House Plan Design - Mediterranean Floor Plan - Main Floor Plan #417-761

House Plan Design - Mediterranean Floor Plan - Upper Floor Plan #417-761

Jump to:
All (4)
Exterior (2)
Floor plans (2)

Get Personalized Help

Home > Style > Mediterranean Home Plans

Key Specs

6549
sq ft

5
Beds

5
Baths

2
Floors

4
Garages

Select Plan Set Options

What's included?

Additional options

Audio Video Design

$100.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide

$39.00

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design

$200.00

Receive an overlay sheet with suggested placement of lighting fixtures.

Mirror Reversed Sets

$30.00

Printed sets showing plan in reverse, text and dimensions will be backwards.

Subtotal

$3150.00

Also order by phone: 1-800-528-8070

Get Personalized Help

When do you want to start construction? Do you have a lot? Are you working with a builder? Where do you plan on building? * Please enter your question(s) *

Send me your Newsletter, too!

We do our best to get back to you within 24 - 48 business hours.

Need an answer faster? Call now...
Phone: 1-800-528-8070

Hours:

Ready for Your Call 7 Days a Week

Every Day 7 am - 8:30 pm Eastern

See our Terms & Conditions and Privacy Policy.

Wow!

Cost to Build Reports

are Only $4.99
with Code CTB2024 (limit 1)

This report will provide you cost estimates based on location and building materials.

Get Cost-To-Build Report

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

Get the Guide

PLAN 417-761

Home > Style > Mediterranean Home Plans

Key Specs

6549
sq ft

5
Beds

5
Baths

2
Floors

4
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.

Modify This Plan

Plan Description

This Italian Renaissance marvel has it all--five bedrooms, a game room, a theater, and expansive areas for formal parties and relaxed barbecues. A covered patio winds around the entire rear of the home, and a sundeck is located on the second level. A wet bar and circular balcony, with an outside spiral stairway, make the upstairs game room a great party site. The lavish master suite features a circular sitting area with windows drawing in natural light from many directions. A spiral stairway winds gracefully upstairs from the impressive main-floor entry, or, if you prefer, take the elevator. A semicircular turret on the corner of the three-car garage is not only flashy, it is a handy storage area.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Full Specs & Features

Dimension

Depth : 102' 8"

Height : 32'

Width : 98' 8"

Area

Bonus: 453 sq/ft

First Floor: 4323 sq/ft height 12'

Second Floor: 2226 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 4:12

Roof Framing : Truss

Roof Type : Tile

Exterior Wall Framing

Exterior Wall Finish : Stone/Stucco

Framing : Block

Bedroom Features

Fireplace

Guest Suite

Main Floor Master Bedroom

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Hobby Rec Room Game Room

Loft

Main Floor Laundry

Master Sitting Area

Media Room

Sunroom

Unfinished Future Space

Outdoor Spaces

Balcony

Courtyard

Covered Rear Porch

Screened Porch

Rooms

3rd BR Closet:

17 sq/ft width 6' 6" x depth 2' 9"

Bathroom 2:

44 sq/ft width 8' x depth 5' 6"

Bathroom 3:

100 sq/ft width 7' x depth 14' 4"

Bedroom 2:

224 sq/ft width 17' 3" x depth 13'

Bedroom 2 Closet:

25 sq/ft width 4' 8" x depth 5' 6"

Bedroom 3:

182 sq/ft width 14' x depth 13'

Bedroom 3 Closet:

25 sq/ft width 4' 8" x depth 5' 6"

Bedroom 4:

189 sq/ft width 13' 6" x depth 14'

Bedroom 4 Closet:

15 sq/ft width 7' 6" x depth 2'

Bedroom 5:

157 sq/ft width 11' 8" x depth 13' 6"

Bonus Room - Finished:

396 sq/ft width 15' 3" x depth 26'

Breakfast Room:

96 sq/ft width 8' x depth 12'

Den/Office or Bedroom 1:

177 sq/ft width 14' x depth 12' 8"

Foyer:

153 sq/ft width 11' 8" x depth 13' 2"

Game Room:

530 sq/ft width 18' 6" x depth 28' 8"

Garage:

737 sq/ft width 35' 8" x depth 20' 8"

Gathering Room:

463 sq/ft width 19' 4" x depth 24'

Kitchen:

263 sq/ft width 17' x depth 15' 6"

Laundry Room:

58 sq/ft width 8' x depth 7' 3"

Living Room:

width 0" x depth 4"

Master Bathroom:

300 sq/ft width 13' 8" x depth 22'

Master Bedroom:

362 sq/ft width 16' x depth 22' 8"

Master Closet:

219 sq/ft width 11' 3" x depth 19' 6"

Porch - Left:

370 sq/ft width 37' x depth 10'

Porch - Right:

670 sq/ft width 60' 11" x depth 11'

Powder Room:

54 sq/ft width 8' x depth 6' 10"

Study:

66 sq/ft width 8' x depth 8' 4"

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Questions? Call 1-800-528-8070

Plan Set

PDF Set:
$3150.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Single Build:
$6300.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Study Set:
$1000.00

One electronic set for bidding purposes only. Not a legal building set for construction.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Block:
$0.00

Concrete Block Exterior Walls (Upper Levels may be wood-framed)

Additional Options

Audio Video Design:
$100.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$39.00

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$200.00

Receive an overlay sheet with suggested placement of lighting fixtures.

Mirror Reversed Sets:
$30.00

A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
