Depth : 69' 4"
Height : 24'
Width : 75' 10"
First Floor: 2626 sq/ft height 8'
Garage: 637 sq/ft
Porch: 1500 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 4:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x6
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
Den Office Study Computer
Great Room Living Room
Master Sitting Area
Rear Entry Garage
Suited For Corner Lot
Suited For View Lot
Covered Front Porch
Wrap Around Porch
583 sq/ft width 23' 6" x depth 24' 10"
177 sq/ft width 7' 2" x depth 24' 10"
584 sq/ft width 24' 2" x depth 24' 2"
63 sq/ft width 9' x depth 7'
Porch - Front:
568 sq/ft width 75' 10" x depth 7' 6"
Porch - Left:
270 sq/ft width 36' x depth 7' 6"
Porch - Right:
270 sq/ft width 36' x depth 7' 6"
