Key Specs


2200
sq ft

2
Beds

2.5
Baths

1
Floors

3
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing.

Need a quote fast? Call us at 1-800-528-8070.

Plan Description


• This modern-style ranch with sleek details makes use of every inch of living space. • The open concept living space includes a kitchen dining and great room space that is large enough for family gathering. • The master suite lies to the right of the entry and includes a spacious walk-in closet and dual sinks. • The second bedroom is found to the left of the entry and pleases with its private bath and walk-in closet. The den lies to the right of the entry but can also be used as a third bedroom. • A large covered porch is accessed off the dining area to provide even more living area. • The three-stall garage is a side-load with extra storage.

Floor Plans


Floor Plan - Main Floor Plan
Ranch Floor Plan - Main Floor Plan Plan #70-1422

Full Specs & Features


Dimension
Depth : 55' 4"
Height : 20' 4"
Width : 87'
Area
Garage : 715 sq/ft
Main Floor : 2200 sq/ft
Ceiling
Ceiling Details : Kit, Din, Grt, Den, Entry 12'.
Main Ceiling : 10'
Roof
Roof Framing : Truss
Roof Load : 47 lbs psf
Primary Pitch : 5:12
Secondary Pitch : 5:12
Exterior Wall Framing
Insulation : R-20
Exterior Wall Finish : Stucco. Stone. Horizontal Siding.
Framing : 2x6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Eating Bar
Kitchen Island
Breakfast Nook
Walk In Pantry Cabinet Pantry
Additional Room Features
Mud Room
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Storage Area
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Empty Nester
Suited For Vacation Home

What's Included In This Plan Set


  • Cover sheet with front rendering
  • Foundation and floor plans at 1/4" = 1' scale
  • Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
  • Building sections and details as required to construct the individual design
  • Interior elevation of cabinets at 1/4" = 1' scale
  • Roof plans
  • Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
  • Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
  • Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
