Full Specs & Features
Height : 24'
Width : 81'
Main Ceiling : 8'
Roof Framing : Truss
Roof Type : Shingle
Framing : Wood - 2x6
36 sq/ft width 7' 4" x depth 5'
143 sq/ft width 11' x depth 13'
140 sq/ft width 11' 8" x depth 12'
195 sq/ft width 14' 10" x depth 13' 2"
136 sq/ft width 11' 8" x depth 11' 8"
192 sq/ft width 11' x depth 17' 6"
893 sq/ft width 36' x depth 24' 10"
25 sq/ft width 4' 11" x depth 5' 3"
190 sq/ft width 14' 6" x depth 13' 2"
98 sq/ft width 7' 11" x depth 12' 6"
192 sq/ft width 13' 4" x depth 14' 5"
37 sq/ft width 10' x depth 3' 9"
46 sq/ft width 8' 2" x depth 5' 8"
