PLAN 943-45

Plan Description


Vaulted ceilings give this 1,952-square-foot home a wonderfully open feeling, making it seem larger than it actually is. On the exterior, the side-entry garage keeps the focus on the attractive front elevation, where Craftsman-style columns and a variety of siding types add lots of curb appeal. Inside, the kitchen takes center stage. A snack bar provides space for casual meals, with the dining room near the front for special occasions. Work from home (or homeschool) in the den, tucked away on the left side of the home. On the opposite side, the master suite offers double sinks and a large walk-in closet.

Full Specs & Features


Dimension

Depth : 48'

Height : 18' 9"

Width : 55'

Area

First Floor: 1952 sq/ft height 8'

Garage: 398 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 8:12

Roof Framing : Truss

Roof Type : Shingle

Secondary Pitch : 6:12

Exterior Wall Framing

Exterior Wall Finish : Shingle/Siding

Framing : Wood - 2x6

Bedroom Features

Fireplace

Formal Dining Room

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Kitchen Island

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Great Room Living Room

Main Floor Laundry

Open Floor Plan

Vaulted / Cathedral Ceilings

Garage Features

Side Entry Garage

Outdoor Spaces

Covered Front Porch

Rooms

Bedroom 2:

151 sq/ft width 13' 2" x depth 11' 6"

Bedroom 3:

165 sq/ft width 13' 2" x depth 12' 6"

Covered Front Porch:

95 sq/ft

Den:

138 sq/ft width 13' 2" x depth 10' 6"

Dining Room:

117 sq/ft width 10' x depth 11' 8"

Garage:

398 sq/ft

Great Room:

338 sq/ft width 25' x depth 13' 6"

Master Bedroom:

200 sq/ft width 13' 2" x depth 15' 2"

What's Included


All plans are drawn at ¼” scale or larger and include :
  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
» See important information before purchasing.
Questions? Call 1-800-528-8070

Plan Set

5 Copy Set:
$654.50
5 printed plan sets mailed to you.
8 Copy Set:
$709.75
8 printed plan sets mailed to you.
PDF Set:
$794.75
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set:
$833.00
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set:
$1283.50
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Single Set:
$607.75
One printed set for bidding purposes only. Not a legal building set for construction.

Foundation

Crawlspace:
$0.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x6:
$0.00
Wood 2x6 Exterior Walls

Additional Options

Right-Reading Reverse:
$148.75
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets:
$51.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
$85.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide:
$33.15
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design:
$85.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets:
$51.00
