PLAN 120-262

Plan Description


Here’s a surprisingly upscale design under 1,500 square feet. The open gathering areas feature French doors to the back lanai, where a fireplace invites outdoor relaxation on cool evenings. The master suite and one of the secondary bedrooms also open out to this oasis. Don’t miss the well-organized utility area on the way in from the garage or the versatile bonus spaces upstairs.

Floor Plans


Floor Plan - Main Floor

Reverse
Save

Floor Plan - Upper Floor

Reverse
Save

Full Specs & Features


Dimension

Depth : 51'

Height : 26' 7"

Width : 68' 11"

Area

Bonus : 513 sq/ft

Garage : 603 sq/ft

Main Floor : 1486 sq/ft

Porch : 447 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 10'

Upper Ceiling Ft : 8'

Roof

Primary Pitch : 12/12

Roof Framing : Conventional

Roof Type : Composition

Secondary Pitch : 3/12

Exterior Wall Framing

Exterior Wall Finish : Brick/Siding

Framing : 2x4

Bedroom Features

Split Bedrooms

Walk In Closet

Kitchen Features

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room

Main Floor Laundry

Unfinished Future Space

Garage Features

Side Entry Garage

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

More

Economical To Build

Rooms

2-Car Garage:

width 21' 8" x depth 25' 5"

Bathroom:

width 7' 7" x depth 6'

Bedroom 1:

width 11' x depth 12'

Bedroom 2:

width 11' x depth 11'

Dining:

width 11' x depth 12' 4"

Family Room:

width 14' x depth 18' 10"

Foyer:

width 8' x depth 6'

Kitchen:

width 8' 6" x depth 14'

Lanai:

width 17' x depth 15'

Master Bath:

width 7' 7" x depth 7' 11"

Master Suite:

width 13' x depth 16'

Porch:

width 20' x depth 5' 7"

Utility:

width 14' x depth 6' 8"

Walk-In Closet:

width 7' 7" x depth 5' 10"

What's Included


  • Designer offers a 2nd Build License for $395 with a PDF purchase as well as an Unlimited License for $395 with the purchase of a CAD.
  • Floor Plans – ¼”=1’-0” scale floor plan indicating location of frame and masonry walls, support members, doors, windows, plumbing fixtures, cabinets, shelving, ceiling conditions and notes deemed relevant to this plan.
  • Exterior Elevations – All elevations at ¼” = 1’-0” scale in most cases. Some older designs may contain 1/8” scale side and rear elevations. Drawing will indicate overall configuration of home at each side view and make note of plate heights, roof overhangs, window header heights, roof pitches, materials used and extent to which they are used and enlargement of any details we feel necessary to explain the construction.
  • Building Sections – ¼” = 1’-0” building sections are included when there is no other reasonable way to indicate the volumetric/height conditions in the home. Most of this information can usually be determined from the exterior elevations.
  • Cabinet Elevations – 3/8” = 1’-0” scale elevations indicating configuration of cabinets, heights, widths, type of components used, cabinet material and finish, counter surfaces, appliances.
  • Framing Plans – ¼” – 1’-0” scale framing plans indicating size and spacing of members as well as bracing and blocking required for structural purposes. Local codes will most likely need to be consulted.
  • Foundation Plans – ¼” = 1’-0” scale foundation plans indicating location of structural walls, grade beams, reinforcing steel and structural columns. Consulting a local engineer is advisable as well as is analysis of soil conditions on site.
  • Electrical Plans – ¼” = 1’-0” scale schematic plans indicating location and types of electrical fixtures, switches, outlets, and how they are to be switched.
