PLAN #472-179

Photographs may show modified designs.

Save

Select Plan Set Options

What's included?
Additional Construction Sets
$40.00/each
Subtotal
$695.00
Also order by phone: 1-800-528-8070
Cost-to-Build Estimates
How much will this cost to build?
This report will provide you cost estimates based on location and building materials.
Questions?
Questions?

We do our best to get back within 24 - 48 business hours.
Need an answer fast? Call us now.
Hours  Mon-Fri, 9 am - 8:30 pm (EST)

PLAN #472-179

Key Specs


1468
sq ft

3
Beds

2
Baths

1
Floors

0
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing.

Need a quote fast? Call us at 1-800-528-8070.

Plan Description


Wide porch pillars lend Craftsman flair to this tidy stucco bungalow. Inside, the spacious living room features a corner niche and a nearby coat closet. Columns define the formal dining room, located between the living room and kitchen; the kitchen opens to a covered rear patio. All three bedrooms—a master suite and two additional bedrooms—boast walk-in closets. The master suite provides a private bath, and the two secondary bedrooms share a full hall bath. The utility area offers an extra closet for linen storage. <p>As per the Texas Board of Architectural Examiners, Reproducible and CAD versions of this plan are not permitted for sale to persons with Texas addresses. You may order 1-sets, 5-sets, or 8-sets. Contact Hanley Wood Customer service at 888.846.8188 with any questions.</p>

Floor Plans


Floor Plan - Main Floor Plan
Craftsman Floor Plan - Main Floor Plan Plan #472-179

Full Specs & Features


Dimension
Depth : 55' 8"
Height : 22'
Width : 36' 2"
Area
First Floor: 1468 sq/ft height 10'
Roof
Roof Framing : Conventional
Primary Pitch : 6:12
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Wood - 2x4
Bedroom Features
Walk In Closet
Formal Dining Room
Formal Living Room / Parlor
Additional Room Features
Main Floor Laundry
Open Floor Plan
Outdoor Spaces
Courtyard
Covered Front Porch
Covered Rear Porch
Rooms

3rd BR Closet:

24 sq/ft width 4' x depth 6'

Bedroom 2:

143 sq/ft width 11' 8" x depth 12' 4"

Bedroom 2 Closet:

20 sq/ft width 4' x depth 5'

Bedroom 3:

122 sq/ft width 11' 2" x depth 11'

Bedroom 3 Closet:

20 sq/ft width 4' x depth 5'

Deck:

140 sq/ft width 14' x depth 10'

Dining Room:

143 sq/ft width 14' 10" x depth 9' 8"

Garage:

480 sq/ft width 20' x depth 24'

Hall Bathroom:

37 sq/ft width 5' x depth 7' 6"

Hall Closet:

6 sq/ft width 3' 2" x depth 2'

Kitchen:

197 sq/ft width 14' 10" x depth 13' 4"

Living Room:

268 sq/ft width 19' 8" x depth 13' 8"

Master Bathroom:

74 sq/ft width 8' 4" x depth 9'

Master Bedroom:

163 sq/ft width 11' 8" x depth 14'

Master Closet:

48 sq/ft width 8' x depth 6'

Porch - Front:

133 sq/ft width 20' x depth 6' 8"

Utility Room:

40 sq/ft width 7' x depth 5' 10"

What's Included In This Plan Set


  • ELECTRICAL SCHEMATIC
  • EXTERIOR ELEVATIONS
  • CABINET ELEVATIONS
  • CEILING FRAMING
  • ROOF FRAMING
  • FOUNDATION OF CHOICE AS AVAILABLE (SLAB, CRAWLSPACE OR BASEMENT) APPROPRIATE FOUNDATION DETAIL SHEET
  • BUILDING CROSS SECTION IF MULTISTORY
  • ALSO 4 PAGE FHA DESCRIPTION OF MATERIALS FORM (NOT A MATERIALS LIST OF QUANTITIES)
  • GENERIC WALL SECTIONS
    Note: Reproducible and CAD files are not available if building in Texas, Oklahoma, New Mexico, or Louisiana. Architect must update and stamp all plans being sent to these states.
» See important information before purchasing.
