Full Specs & Features
Height : 39' 3"
Width : 85' 3"
Bonus: 666 sq/ft
First Floor: 1762 sq/ft
Second Floor: 1813 sq/ft
Third Floor: 959 sq/ft
Roof Framing : Truss
Roof Type : Asphalt
Framing : Wood - 2x6
Formal Dining Room
Formal Living Room / Parlor
Upstairs Master Bedrooms
Walk In Closet
Kitchenette Wet Bar
Family Room Keeping Room
Great Room Living Room
Hobby Rec Room Game Room
Open Floor Plan
Unfinished Future Space
Vaulted / Cathedral Ceilings
Covered Front Porch
Wrap Around Porch
123 sq/ft width 11' 9" x depth 10' 6"
119 sq/ft width 11' 9" x depth 10' 2"
140 sq/ft width 13' 2" x depth 10' 8"
164 sq/ft width 13' 11" x depth 11' 10"
294 sq/ft width 14' x depth 21'
52 sq/ft width 9' 6" x depth 5' 6"
136 sq/ft width 11' 6" x depth 11' 10"
787 sq/ft width 31' 6" x depth 25'
225 sq/ft width 13' 8" x depth 16' 6"
304 sq/ft width 14' 6" x depth 21'
77 sq/ft width 15' x depth 5' 2"
357 sq/ft width 17' x depth 21'
112 sq/ft width 14' x depth 8'
249 sq/ft width 17' x depth 14' 8"
width 16' 8" x depth 20'
What's Included In This Plan Set
Please note: If you are building a Visbeen Architects design in the state of Michigan, please give us a call to confirm availability. Construction in the state of Michigan requires special permission from the Architect.
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
|PDF Set :
|PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|CAD Set :
|For use by design professionals to make substantial changes to your house plan and inexpensive local printing.|
|Ideal for level lot, lower level of home partially or fully underground.|
|Right-Reading Reverse :
|Choose this option to reverse your plans and to have the text and dimensions readable.|
|Audio Video Design :
|Receive an overlay sheet with suggested placement of audio and video components.|
|Construction Guide :
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Lighting Design :
|Receive an overlay sheet with suggested placement of lighting fixtures.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
