PLAN #117-847

ON SALE!

Select Plan Set Options

What's included?
Additional Construction Sets
$45.00/each
Subtotal
NOW $832.50
You save $92.50
(10% savings)
Sale ends 6/27/18
Also order by phone: 1-800-528-8070
Cost-to-Build Estimates

How much will this cost to build?

This report will provide you cost estimates based on location and building materials.

Get Cost-To-Build Report
Or order by phone: 1-800-528-8070
Got Questions?
Got Questions?
Hours  Mon-Fri, 6am - 5:30pm PST

PLAN #117-847

Key Specs


4544
sq ft

4
Beds

3.5
Baths

1
Floors

3
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.

Floor Plans


Floor Plan - Main Floor Plan
Ranch Floor Plan - Main Floor Plan Plan #117-847

Full Specs & Features


Dimension
Depth : 95' 7"
Height : 21' 11"
Width : 130' 11"
Area
First Floor: 4544 sq/ft
Garage: 1253 sq/ft
Bedroom Features
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Kitchenette Wet Bar
Breakfast Nook
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Main Floor Laundry
Media Room
Workshop
Garage Features
Side Entry Garage
Outdoor Spaces
Courtyard
Covered Front Porch
Screened Porch Sunroom
Rooms

Bedroom 2:

width 12' x depth 11' 8"

Bedroom 3:

width 12' 2" x depth 20'

Courtyard:

width 45' x depth 50' 4"

Covered Front Porch:

width 10' 8" x depth 10'

Family Room:

width 24' 6" x depth 23' 4"

Foyer:

width 12' 4" x depth 8'

Guest Dining Area:

width 11' x depth 9' 6"

Guest Dining Area:

width 11' x depth 9' 6"

Guest Kitchen:

width 10' 6" x depth 8' 6"

Guest Living Area:

width 13' 6" x depth 21' 8"

Guest Master Suite:

width 14' x depth 14' 6"

Guest Screened Porch:

width 15' x depth 7' 6"

Kitchen:

width 15' x depth 17'

Master Closet/Dressing Room:

width 9' x depth 10' 10"

Master Suite:

width 15' x depth 18'

Mechanical Room:

width 15' 8" x depth 6'

Media Room:

width 14' 4" x depth 12'

Nook:

width 11' x depth 10'

Office:

width 16' x depth 16'

Shop:

width 22' x depth 21' 4"

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
Plan Set
5 Copy Set :
$832.50
5 printed plan sets mailed to you.
8 Copy Set :
$900.00
8 printed plan sets mailed to you.
Reproducible Set :
$1080.00
For making minor changes to your house plans and inexpensive local printing. 1 printed set on Vellum or Bond paper.
CAD Set :
$1170.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
PDF Set :
$1170.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Single Set :
$135.00
One printed set for bidding purposes only. Not a legal building set for construction.
Foundation
Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.
Framing
Insulated Concrete Forms:
$0.00
Insulated Concrete Forms
Additional Options
Right-Reading Reverse :
45.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets :
45.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Home Furniture Planner :
17.10
This fun visual aid lets you peel-and-stick furniture on a generic layout to plan out spacing.
Lighting Design :
90.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Audio Video Design :
90.00
Receive an overlay sheet with suggested placement of audio and video components.
