Full Specs & Features
Height : 37'
Width : 64' 10"
Bonus: 176 sq/ft
First Floor: 2425 sq/ft height 9'
Second Floor: 1398 sq/ft
Roof Framing : Conventional
Framing : Wood - 2x4
186 sq/ft width 12' x depth 15' 6"
232 sq/ft width 13' 8" x depth 17'
141 sq/ft width 12' 8" x depth 11' 2"
Bonus Room - Finished:
176 sq/ft width 16' x depth 11'
135 sq/ft width 11' 4" x depth 12'
171 sq/ft width 12' 8" x depth 13' 6"
526 sq/ft width 26' 4" x depth 20'
243 sq/ft width 19' 6" x depth 12' 6"
425 sq/ft width 23' x depth 18' 6"
252 sq/ft width 18' x depth 14'
79 sq/ft width 11' 4" x depth 7'
255 sq/ft width 15' x depth 17'
91 sq/ft width 9' 4" x depth 9' 10"
140 sq/ft width 12' x depth 11' 8"
What's Included In This Plan Set
- Dimensioned and detailed Foundation plan (type as listed on home plan description)
- Dimensioned and detailed floor plans
- Framing plans (framing may be shown on floor plans in some cases.)
- Complete front, side and rear elevations
- Roof plan
- Typical building sections (as deemed necessary for construction)
- Typical foundation details, wall sections, and cornice details necessary for construction
- Separate electrical plan (may be shown on floor plans in some cases)
|PDF Set :
|PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|Reproducible Set :
|For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.|
|Ideal for level lot, lower level of home partially or fully underground.|
|Additional Construction Sets :
|Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).|
|Audio Video Design :
|Receive an overlay sheet with suggested placement of audio and video components.|
|Construction Guide :
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Lighting Design :
|Receive an overlay sheet with suggested placement of lighting fixtures.|
|Mirror Reversed Sets :
|A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
