PLAN 1066-74
Key Specs
4417
sq ft
5
Beds
4.5
Baths
2
Floors
3
Garages
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Full Specs & Features
Dimension
Depth : 56'
Height : 36' 5"
Width : 55'
Height : 36' 5"
Width : 55'
Area
Garage : 667 sq/ft
Lower Floor : 381 sq/ft
Main Floor : 2207 sq/ft
Patios : 162 sq/ft
Porch : 60 sq/ft
Upper Floor : 1829 sq/ft
Lower Floor : 381 sq/ft
Main Floor : 2207 sq/ft
Patios : 162 sq/ft
Porch : 60 sq/ft
Upper Floor : 1829 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : Master suite has a vaulted ceiling.
Garage Ceiling : 11' 6"
Lower Ceiling : 10'
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Garage Ceiling : 11' 6"
Lower Ceiling : 10'
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Roof
Primary Pitch : 5/12
Roof Framing : Trusses and Some Raftors
Roof Load : 25 PSF
Roof Type : Composition Shingles
Roof Framing : Trusses and Some Raftors
Roof Load : 25 PSF
Roof Type : Composition Shingles
Exterior Wall Framing
Exterior Wall Finish : Siding, Panels, and Stone Veneer
Framing : 2X6
Insulation : R21
Framing : 2X6
Insulation : R21
Bedroom Features
Main Floor Bedrooms
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Butler's Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Upstairs Laundry
Great Room Living Room
Upstairs Laundry
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Sloping Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Covered Rear Porch
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
