PLAN 417-711
Key Specs
3923
sq ft
3
Beds
2
Baths
2
Floors
4
Garages
Cost to Build Reports Only $9.99 for a Limited Time! Use Code CTB2021
This report will provide you cost estimates based on location and building materials.
Phone: 1-800-528-8070
See our Terms & Conditions and Privacy Policy.
PLAN 417-711
Key Specs
3923
sq ft
3
Beds
2
Baths
2
Floors
4
Garages
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.Plan Description
The castle-like facade of this romantic fairy tale home encloses a floor plan fit for royalty. Dazzling turrets, French accents and a stately presence give this home a dramatic European appeal. The entry leads inside to a foyer flanked on either side by a den/office and a formal dining room. A curved staircase is placed behind the living room, which overlooks the rear porch. The master suite features a spacious sitting area and a lavish bath that includes two vanities, His and Hers walk-in closets, an oval tub and a separate shower. Casual areas of the home include the kitchen overlooking the breakfast nook and the open two-story family room with a warming fireplace. The family room accesses the rear covered porch, while the breakfast nook connects to a side patio. Upstairs, Bedrooms 2 and 3 with walk-in closets share a bath. An unfinished room at the end of the hall is great for a fourth bedroom or home office. Double doors open into an activity room that accesses a balcony. The home theater accesses an enormous bonus room.
Full Specs & Features
Height : 35'
Width : 74'
First Floor: 2553 sq/ft height 10'
Second Floor: 1370 sq/ft
Roof Framing : Truss
Roof Type : Shingle
Framing : ICF (Insulated Concrete Forms)
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Main Floor Laundry
Master Sitting Area
Media Room
Storage Area
Unfinished Future Space
Courtyard
Covered Front Porch
Deck
Balcony:
264 sq/ft width 23' 4" x depth 11' 4"
Garage:
946 sq/ft width 43' x depth 22'
Patio:
330 sq/ft width 30' x depth 11'
Porch - Rear:
272 sq/ft width 23' 4" x depth 11' 8"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
| PDF Set
: $1450.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set
: $1650.00 |
5 printed plan sets mailed to you. |
| 5 Copy and PDF Set
: $1800.00 |
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| CAD Single Build
: $2900.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
| Study Set
: $800.00 |
One electronic set for bidding purposes only. Not a legal building set for construction. |
Foundation
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Framing
| Insulated Concrete Forms: $0.00 |
Insulated Concrete Forms |
Additional Options
| Additional Construction Sets
: $50.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design
: $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide
: $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design
: $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets
: $30.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
