Full Specs & Features
Height : 19' 9"
Width : 86'
Basement Unfinished: 582 sq/ft
First Floor: 2194 sq/ft height 10'
Garage: 930 sq/ft
Roof Framing : Truss
Roof Type : Asphalt
Secondary Pitch : 4:12
Framing : Wood - 2x6
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchenette Wet Bar
Family Room Keeping Room
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Open Floor Plan
Covered Front Porch
Covered Rear Porch
213 sq/ft width 14' 6" x depth 14' 8"
146 sq/ft width 13' 2" x depth 11' 1"
151 sq/ft width 13' 2" x depth 11' 6"
336 sq/ft width 18' 8" x depth 18'
150 sq/ft width 11' x depth 13' 8"
243 sq/ft width 13' 6" x depth 18'
930 sq/ft width 23' x depth 35'
178 sq/ft width 15' 6" x depth 11' 6"
228 sq/ft width 12' 4" x depth 18' 6"
358 sq/ft width 19' 4" x depth 18' 6"
191 sq/ft width 13' 8" x depth 14'
130 sq/ft width 11' x depth 11' 10"
What's Included In This Plan Set
Please note: If you are building a Visbeen Architects design in the state of Michigan, please give us a call to confirm availability. Construction in the state of Michigan requires special permission from the Architect.
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
|PDF Set :
|PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|CAD Set :
|For use by design professionals to make substantial changes to your house plan and inexpensive local printing.|
|Ideal for sloping lot, lower level of home partially underground.|
|Right-Reading Reverse :
|Choose this option to reverse your plans and to have the text and dimensions readable.|
|Audio Video Design :
|Receive an overlay sheet with suggested placement of audio and video components.|
|Construction Guide :
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Lighting Design :
|Receive an overlay sheet with suggested placement of lighting fixtures.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
