Key Specs


3124
sq ft

4
Beds

3.5
Baths

2
Floors

2
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing.

Need a quote fast? Call us at 1-800-528-8070.

Plan Description


On entering this home, a graceful, curved staircase rises through the two-story entry to draw your eye upward. Down three stairs, the living room features a complete window wall overlooking the rear. Upstairs, the home is completed with three bedrooms and two full baths.

Floor Plans


Floor Plan - Main Floor Plan
Mediterranean Floor Plan - Main Floor Plan Plan #952-23
Floor Plan - Upper Floor Plan
Mediterranean Floor Plan - Upper Floor Plan Plan #952-23

Full Specs & Features


Dimension
Depth : 64' 2"
Height : 35'
Width : 74' 9"
Area
First Floor: 2263 sq/ft
Second Floor: 861 sq/ft
Roof
Roof Framing : Conventional
Primary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Bedroom Features
Walk In Closet
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Kitchen Features
Kitchen Island
Kitchenette Wet Bar
Breakfast Nook
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Master Sitting Area
Loft
Outdoor Spaces
Covered Front Porch
Balcony
Rooms

Bedroom 2:

137 sq/ft width 10' 1" x depth 13' 8"

Bedroom 3:

139 sq/ft width 12' 4" x depth 11' 4"

Bedroom 4:

182 sq/ft width 15' x depth 12' 2"

Breakfast Room:

171 sq/ft width 12' 8" x depth 13' 6"

Den/Office or Bedroom 1:

120 sq/ft width 10' 4" x depth 11' 8"

Dining Room:

173 sq/ft width 11' 7" x depth 15'

Garage:

455 sq/ft width 21' 4" x depth 21' 4"

Gathering Room:

197 sq/ft width 13' x depth 15' 2"

Kitchen:

225 sq/ft width 15' x depth 15'

Living Room:

347 sq/ft width 16' 10" x depth 20' 8"

Master Bedroom:

250 sq/ft width 13' 8" x depth 18' 4"

Master Closet:

82 sq/ft width 6' x depth 13' 8"

Study:

120 sq/ft width 11' 8" x depth 10' 4"

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
