Plan Description

Gracious living fits this splendid one-story home like a hand in a glove. Memorable evenings dining and socializing with friends will be enjoyed in the spacious living room and elegant dining area. Through French doors the partying can extend out to a covered deck. The kitchen, with a walk-in pantry, is designed to work well together with the breakfast alcove and a sunlit family room. A front study offers a retreat for reading or writing. The master suite, with a dreamy bath, is separated from the three family bedrooms for privacy.

As per the Texas Board of Architectural Examiners, Reproducible and CAD versions of this plan are not permitted for sale to persons with Texas addresses. You may order 1-sets, 5-sets, or 8-sets. Contact Zonda Customer service at 888.846.8188 with any questions.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 76' 11"

Height : 31'

Width : 69' 11"

Area

First Floor: 3029 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 10:12

Roof Framing : Conventional

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick

Framing : Wood - 2x4

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Split Bedrooms

Kitchen Features

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Family Room Keeping Room

Main Floor Laundry

Open Floor Plan

Garage Features

Side Entry Garage

Outdoor Spaces

Courtyard

Covered Front Porch

Covered Rear Porch

Rooms

Bathroom 2:

53 sq/ft width 5' x depth 10' 8"

Bathroom 3:

53 sq/ft width 5' x depth 10' 8"

Bedroom 2:

224 sq/ft width 14' 4" x depth 15' 8"

Bedroom 3:

149 sq/ft width 10' 8" x depth 14'

Bedroom 4:

182 sq/ft width 13' 4" x depth 13' 8"

Breakfast Room:

80 sq/ft width 8' x depth 10'

Garage:

462 sq/ft width 21' x depth 22'

Gathering Room:

193 sq/ft width 15' 6" x depth 12' 6"

Hall:

63 sq/ft width 3' x depth 21'

Kitchen:

300 sq/ft width 15' x depth 20'

Master Bathroom:

198 sq/ft width 12' 8" x depth 15' 8"

Master Bedroom:

291 sq/ft width 18' x depth 16' 2"

Master Closet:

64 sq/ft width 6' 8" x depth 9' 8"

Master Closet Two:

17 sq/ft width 3' 4" x depth 5' 2"

Porch - Front:

144 sq/ft width 8' x depth 18'

Porch - Rear:

171 sq/ft width 9' x depth 19'

Powder Room:

25 sq/ft width 5' x depth 5'

Study:

146 sq/ft width 11' x depth 13' 4"

Utility Room:

58 sq/ft width 8' 10" x depth 6' 8"

What's Included In This Plan Set

See a sample plan set

ELECTRICAL SCHEMATIC
EXTERIOR ELEVATIONS
CABINET ELEVATIONS
CEILING FRAMING
ROOF FRAMING
FOUNDATION OF CHOICE AS AVAILABLE (SLAB, CRAWLSPACE OR BASEMENT) APPROPRIATE FOUNDATION DETAIL SHEET
BUILDING CROSS SECTION IF MULTISTORY
ALSO 4 PAGE FHA DESCRIPTION OF MATERIALS FORM (NOT A MATERIALS LIST OF QUANTITIES)
GENERIC WALL SECTIONS

Note: Reproducible (PDF) and CAD plans are not available if building in Texas, Oklahoma, New Mexico, Louisiana, Tennessee, Arkansas, or Alabama. Architect must update and stamp all plans being sent to these states.
