PLAN 417-508

Home > Style > Mediterranean Home Plans

Key Specs

2646
sq ft

4
Beds

2.5
Baths

2
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.

Modify This Plan

Plan Description

A striking use of keystone banding helps to create the majestic elevation of this home. Inside, versatility is the operative word for this plan and its large spaces: formal entertaining and casual family living take off with the expansive dining, family and game rooms. Access to the covered patio is found in the master bedroom, the game room and off the breakfast area. The master bedroom, with its vaulted ceiling, features His and Hers closets and a bath with a soaking tub and a large shower. Upstairs, three bedrooms share a loft space that's perfect for the kids. A cleverly arranged hall bath offers a double-bowl vanity. If desired, Bedroom 2 may support a private full bath.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Full Specs & Features

Dimension

Depth : 68' 4"

Height : 26'

Width : 40'

Area

First Floor: 1766 sq/ft height 8'

Second Floor: 880 sq/ft height 8'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 7:12

Roof Framing : Truss

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Wood - 2x4

Bedroom Features

Formal Dining Room

Formal Living Room / Parlor

Split Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room

Great Room Living Room

Hobby Rec Room Game Room

Loft

Outdoor Spaces

Balcony

Courtyard

Covered Front Porch

Covered Rear Porch

Deck

Rooms

Bedroom 2:

177 sq/ft width 13' 4" x depth 13' 4"

Bedroom 3:

143 sq/ft width 13' x depth 11'

Bedroom 4:

143 sq/ft width 13' x depth 11'

Breakfast:

104 sq/ft width 11' 6" x depth 9'

Dining Room:

99 sq/ft width 11' x depth 9'

Game Room:

289 sq/ft width 17' 8" x depth 17' 4"

Gathering Room:

195 sq/ft width 15' x depth 13'

Kitchen:

140 sq/ft width 9' x depth 15' 6"

Living Room:

144 sq/ft width 12' x depth 12'

Loft:

173 sq/ft width 8' 8" x depth 20'

Master Bath:

221 sq/ft width 13' x depth 17'

Master Bedroom:

221 sq/ft width 17' x depth 13'

Utility:

44 sq/ft width 8' 10" x depth 5'

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Questions? Call 1-800-528-8070

Plan Set

PDF Set:
$977.50

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

5 Copy Set:
$1147.50

5 printed plan sets mailed to you.

5 Copy and PDF Set:
$1275.00

5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.

CAD Single Build:
$1955.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Study Set:
$595.00

One electronic set for bidding purposes only. Not a legal building set for construction.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x4:
$0.00

Wood 2x4 Exterior Walls

Additional Options

Additional Construction Sets:
$42.50

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design:
$85.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$33.15

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

Lighting Design:
$85.00

Receive an overlay sheet with suggested placement of lighting fixtures.

Mirror Reversed Sets:
$25.50

A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
