PLAN 17-2682

Key Specs

2525
sq ft

4
Beds

3
Baths

1
Floors

2
Garages

This plan can be customized!

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing.

Need a quote fast? Call us at 1-800-528-8070.

Modify This Plan

Plan Description

Perennially popular, this one-story layout makes the grilling porch a priority. Many areas open onto it: the breakfast nook, great room, master suite, and even a hallway near a secondary bedroom. Back inside, the kitchen's snack bar offers another relaxed area to entertain with seating for four. The home theater/living room near the front could also serve as a home office with the addition of some doors. Owners will love the master suite's generous bathroom.

Floor Plans

Floor Plan - Main Floor Plan

Full Specs & Features

Dimension

Depth : 55' 10"
Height : 30' 9"
Width : 67' 2"

Area

First Floor: 2525 sq/ft height 9'
Garage: 497 sq/ft
Porch: 417 sq/ft
Storage: 39 sq/ft

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 10:12
Roof Framing : Conventional
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Brick
Framing : Wood - 2x4

Bedroom Features

Fireplace
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet

Kitchen Features

Breakfast Nook
Kitchenette Wet Bar

Additional Room Features

Great Room Living Room
Main Floor Laundry
Media Room

Outdoor Spaces

Covered Rear Porch
Outdoor Fireplace

Rooms

Bathroom 2:

35 sq/ft width 7' x depth 5'

Bathroom 3:

50 sq/ft width 10' 2" x depth 5'

Bedroom 2:

149 sq/ft width 14' x depth 10' 8"

Bedroom 3:

193 sq/ft width 14' x depth 13' 10"

Bedroom 4:

147 sq/ft width 11' 4" x depth 13'

Breakfast Room:

148 sq/ft width 13' 4" x depth 11' 2"

Dining Room:

186 sq/ft width 11' 6" x depth 16' 3"

Foyer:

66 sq/ft width 8' 10" x depth 7' 6"

Front Entry:

53 sq/ft width 8' x depth 6' 8"

Garage:

497 sq/ft width 21' 4" x depth 23' 4"

Great Room:

363 sq/ft width 18' 2" x depth 20'

Grilling Porch:

431 sq/ft width 30' 10" x depth 14'

Home Theater:

201 sq/ft width 12' x depth 16' 10"

Kitchen:

174 sq/ft width 12' x depth 14' 7"

Laundry Room:

70 sq/ft width 6' x depth 11' 10"

Master Bathroom:

187 sq/ft width 15' x depth 12' 6"

Master Bedroom:

261 sq/ft width 18' 8" x depth 14'

Master Closet:

35 sq/ft width 5' x depth 7'

Storage:

40 sq/ft width 15' x depth 2' 8"
