Full Specs & Features
Height : 26'
Width : 66' 3"
First Floor: 2295 sq/ft
Framing : Wood - 2x4
Walk In Closet
Great Room Living Room
Play Flex Room
Unfinished Future Space
Suited For View Lot
137 sq/ft width 11' 1" x depth 12' 5"
135 sq/ft width 12' 4" x depth 11'
Bonus Room - Unfinished:
209 sq/ft width 12' 1" x depth 17' 4"
148 sq/ft width 13' 6" x depth 11'
148 sq/ft width 11' x depth 13' 6"
413 sq/ft width 20' 8" x depth 20'
324 sq/ft width 17' x depth 19' 1"
276 sq/ft width 14' 9" x depth 18' 9"
161 sq/ft width 12' x depth 13' 5"
What's Included In This Plan Set
- Foundation plan (slab type) ( 1/4"= 1'-0" in most cases)
- Floor plans including electrical layout (1/4" = 1'-0" in most cases)
- Set of elevations (all four sides)
- Building section(s) stairs & vaulted ceiling details
- Roof plan
- Kitchen & bath elevations
- Miscellaneous details
- Typical detail sheets
|5 Copy Set :
|5 printed plan sets mailed to you.|
|8 Copy Set :
|8 printed plan sets mailed to you.|
|PDF Set :
|PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|Reproducible Set :
|For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.|
|CAD Set :
|For use by design professionals to make substantial changes to your house plan and inexpensive local printing.|
|Single Set :
|One printed set for bidding purposes only. Not a legal building set for construction.|
|Ideal for level lot, lower level of home partially or fully underground.|
|Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.|
|Ideal for level lot, single layer concrete poured directly on grade.|
|Additional Construction Sets :
|Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).|
|Audio Video Design :
|Receive an overlay sheet with suggested placement of audio and video components.|
|Construction Guide :
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Lighting Design :
|Receive an overlay sheet with suggested placement of lighting fixtures.|
|Mirror Reversed Sets :
|A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
