Depth : 53' 6"
Height : 24' 3"
Width : 51' 6"
Garage : 254 sq/ft
Main Floor : 1476 sq/ft
Porch : 283 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 8 in 12
Roof Framing : Conventional
Roof Load : Live Load: 30 # / p.s.f. Dead Load: 10 # / p.s.f. Total Load: 40 # / p.s.f.
Roof Type : Shingle & Metal
Secondary Pitch : 4 in 12
Exterior Wall Framing
Framing : 2 x 4
Insulation : R-20
Walk In Closet
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Play Flex Room
Covered Front Porch
Covered Rear Porch
Economical To Build
Suited For Vacation Home
Energy Efficient Features
