PLAN 1010-22

Plan Description


This ranch design floor plan is 1475 sq ft and has 2 bedrooms and 2 bathrooms.

Full Specs & Features


Dimension

Depth : 57' 4"

Height : 26'

Width : 41'

Area

Basement Unfinished: 1475 sq/ft

First Floor: 1475 sq/ft height 9'

Garage: 488 sq/ft height 9'

Porch: 150 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 7:12

Roof Framing : Truss

Roof Type : Asphalt

Secondary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Brick/Shingle/Siding

Framing : Wood - 2x4

Kitchen Features

Kitchen Island

Additional Room Features

Main Floor Laundry

Open Floor Plan

Outdoor Spaces

Covered Front Porch

Rooms

Bedroom 2:

134 sq/ft width 12' x depth 11' 2"

Dining Room:

146 sq/ft width 12' x depth 12' 2"

Garage:

484 sq/ft width 22' x depth 22'

Great Room:

146 sq/ft width 12' x depth 12' 2"

Kitchen:

114 sq/ft width 9' 2" x depth 12' 6"

Master Bedroom:

217 sq/ft width 13' 10" x depth 15' 9"

Master Walk-In Closet:

51 sq/ft width 7' x depth 7' 4"

What's Included


All plans are drawn at ¼” scale or larger and include :
  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Roof Plan: ?” scale; this shows roof rafter or trusses and how the roof is framed.
  • CAD Plans are in AutoDesk Architecture.
