Depth : 88'
Height : 27'
Width : 27'
Garage : 826 sq/ft
Main Floor : 1424 sq/ft
Porch : 337 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling Details : Flat Ceiling
Garage Ceiling : 8' 10"
Main Ceiling : 11'
Roof Framing : Reinforced Concrete
Roof Type : Flat Ceiling
Exterior Wall Framing
Exterior Wall Finish : Plaster
Framing : Reinforced Concrete
Insulation : Wood-fibre Panels
Main Floor Master Bedroom
Upstairs Master Bedrooms
Walk In Closet
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot
Covered Front Porch
Suited For Vacation Home
Energy Efficient Features
