This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
This Barndominium design floor plan is 3479 sq ft and has 5 bedrooms and 3.5 bathrooms.
Floor Plans
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 76' 4"
Width : 133' 10"
Area
Garage : 1632 sq/ft
Main Floor : 3479 sq/ft
Porch : 2079 sq/ft
Storage : 1632 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 10'
Roof
Primary Pitch : 3:12
Roof Load : 45 lbs
Roof Type : stick
Secondary Pitch : 3:12
Exterior Wall Framing
Exterior Wall Finish : board and batten
Framing : 2x4
Insulation : R13
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Additional Room Features
Great Room Living Room
Main Floor Laundry
Workshop
Garage Features
Front Entry Garage
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
Two Family Home
Unusual Shape
What's Included In This Plan Set
