PLAN 928-173
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.Plan Description
Full Specs & Features
Height : 40'
Width : 114'
First Floor: 3739 sq/ft height 10'
Second Floor: 2067 sq/ft height 9'
Roof Framing : Truss
Roof Type : Asphalt
Framing : Wood - 2x6
Formal Dining Room
Formal Living Room / Parlor
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Exercise Room
Family Room Keeping Room
Great Room Living Room
Mud Room
Open Floor Plan
Unfinished Future Space
Upstairs Laundry
Vaulted / Cathedral Ceilings
Workshop
Covered Front Porch
Covered Rear Porch
Deck
Grill Deck Sundeck
Outdoor Kitchen Grill
Wheelchair Adaptable
Bedroom 2:
191 sq/ft width 13' 6" x depth 14' 2"
Bedroom 3:
156 sq/ft width 12' x depth 13'
Bedroom 4:
134 sq/ft width 11' 6" x depth 11' 8"
Bedroom 5:
126 sq/ft width 11' 2" x depth 11' 4"
Bedroom 6:
126 sq/ft width 11' 2" x depth 11' 4"
Breakfast:
126 sq/ft width 7' 5" x depth 17'
Den:
175 sq/ft width 13' 6" x depth 13'
Dining Room:
178 sq/ft width 13' 6" x depth 13' 3"
Garage:
1242 sq/ft width 46' x depth 27'
Kitchen:
276 sq/ft width 16' 3" x depth 17'
Living Room:
440 sq/ft width 23' 2" x depth 19'
Master Bathroom:
175 sq/ft width 13' 6" x depth 13'
Master Bedroom:
182 sq/ft width 13' 6" x depth 13' 6"
What's Included In This Plan Set
Please note: If you are building a Visbeen Architects design in the state of Michigan, please give us a call to confirm availability. Construction in the state of Michigan requires special permission from the Architect.
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
PDF Set : $1695.75 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
CAD Set : $3395.75 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
Daylight Basement: $0.00 |
Ideal for sloping lot, lower level of home partially underground. |
Framing
Wood 2x6: $0.00 |
Wood 2x6 |
Additional Options
Right-Reading Reverse : $165.75 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design : $170.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
