Full Specs & Features
Height : 39'
Width : 76'
First Floor: 2642 sq/ft
Second Floor: 2479 sq/ft
Roof Framing : Conventional
Roof Type : Shingle
Framing : 2"x4"
Walk In Closet
Walk In Pantry Cabinet Pantry
Family Room Keeping Room
Great Room Living Room
Master Sitting Area
Side Entry Garage
Suited For View Lot
Covered Rear Porch
211 sq/ft width 15' 1" x depth 14'
239 sq/ft width 17' 1" x depth 14'
207 sq/ft width 14' x depth 14' 10"
270 sq/ft width 19' 1" x depth 14' 2"
224 sq/ft width 14' 6" x depth 15' 6"
452 sq/ft width 20' 7" x depth 22'
351 sq/ft width 18' 4" x depth 19' 2"
408 sq/ft width 25' 6" x depth 16'
308 sq/ft width 15' 2" x depth 20' 4"
Library - Upper:
231 sq/ft width 16' 10" x depth 13' 9"
399 sq/ft width 19' 2" x depth 20' 10"
What's Included In This Plan Set
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
|PDF Set :
|PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|CAD Set :
|For use by design professionals to make substantial changes to your house plan and inexpensive local printing.|
|CAD and PDF Set :
|For use by design professionals to make substantial changes to your house plan and inexpensive local printing plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.|
|Ideal for level lot, lower level of home partially or fully underground.|
|Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.|
|Ideal for level lot, single layer concrete poured directly on grade.|
|Right-Reading Reverse :
|Choose this option to reverse your plans and to have the text and dimensions readable.|
|Additional Construction Sets :
|Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).|
|Audio Video Design :
|Receive an overlay sheet with suggested placement of audio and video components.|
|Construction Guide :
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Lighting Design :
|Receive an overlay sheet with suggested placement of lighting fixtures.|
|Mirror Reversed Sets :
|A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
