Depth : 65'
Height : 32'
Width : 90'
First Floor: 2834 sq/ft
Second Floor: 1362 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Shake
Exterior Wall Framing
Exterior Wall Finish : Brick/Stone
Framing : Wood - 2x4
Main Floor Master Bedroom
Walk In Closet
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Play Flex Room
Unfinished Future Space
Side Entry Garage
Suited For Corner Lot
Suited For View Lot
