PLAN 124-1111
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.Full Specs & Features
Height : 29' 6"
Width : 59' 4"
Lower Floor : 1547 sq/ft
Main Floor : 2410 sq/ft
Main Ceiling : 10'
Roof Framing : Truss/Stick
Roof Load : 25
Framing : 2x6
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Kitchen Island
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Mud Room
Storage Area
Suited For View Lot
Bedroom 2:
width 12' 4" x depth 13' 6"
Bedroom 2 Closet:
width 5' 4" x depth 6' 8"
Bedroom 3:
width 12' x depth 13' 4"
Bedroom 3 Closet:
width 8' 8" x depth 4' 6"
Bedroom 4:
width 12' 2" x depth 15' 8"
Bedroom 4 Closet:
width 4' x depth 10' 8"
Covered Rear Porch:
width 31' 6" x depth 12'
Dining Room:
width 13' x depth 12' 8"
Family Room:
width 22' 2" x depth 25'
Garage:
width 24' x depth 25'
Great Room:
width 17' 8" x depth 23'
Kitchen:
width 16' x depth 10' 4"
Master Bath:
width 19' 8" x depth 7'
Master Bedroom:
width 17' x depth 15' 8"
Master Closet:
width 13' x depth 10' 4"
Storage:
width 14' 10" x depth 6'
Utility Room:
width 15' 2" x depth 11' 6"
Utility Room Closet:
width 6' 4" x depth 5'
What's Included In This Plan Set
Please note, if ordering a PDF Print Set, it is not-modifiable. The CAD set is best for making local modifications. The "5 set + PDF" combo contains a non-modifiable PDF Print Set. The "8 set + PDF" combo contains a non-modifiable PDF Print Set.
Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
- Artist's Rendering: An artist's drawing of the home, usually viewed from the front, and general construction notes.
- Elevations: Shows the front, sides, and rear, including exterior materials, trim sizes, roof pitches, etc.
- Main Floor Plan: Shows placement and dimensions of walls, doors, & windows. Includes the location of appliances, plumbing fixtures, beams, ceiling heights, etc.
- Second Floor Plan (if any): Shows the second floor in the same detail as the main floor. Includes second floor framing and details.
- Foundation Plan: Shows the location of all concrete footings, floor beams, first floor framing, and foundation details. If there is a basement, a basement plan is included which shows all basement details. Foundation types vary; please call to confirm the foundation type of the plan you are interested in.
- Floor Framing Plan (if any): Shows location and spacing of floor joists and supporting walls or beams.
- Roof Framing Plan: Shows roof outlines, conventional framing/trusses, beams, roof framing details, etc. Specific details such as fireplaces, stairways, decks, etc. Details are drawn at 1/2" = 1' scale, and appear as needed throughout the prints.
- Section: Shows a cross-section of the home. Shows support members, exterior and interior materials, insulation, and foundation.
- Electrical Plan: A schematic layout of all lighting, switches and electrical outlets.
PDF Print Set : $1058.25 |
A non-modifiable, print only PDF file |
5 Copy and PDF Set : $1286.05 |
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
Eight Copy and PDF Set : $1396.55 |
8 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
PDF Master Set : $2018.75 |
An unlocked, modifiable PDF file |
CAD Set : $2205.75 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Master Builder Package : $2426.75 |
Includes CAD Set, PDF Masters and Unlimited Build License |
Single Set : $845.75 |
One printed set for bidding purposes only. Not a legal building set for construction. |
Foundation
Daylight Basement: $0.00 |
Ideal for sloping lot, lower level of home partially underground. |
Framing
Wood 2x6: $0.00 |
Wood 2x6 |
Additional Options
Right-Reading Reverse : $361.25 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
Additional Construction Sets : $55.25 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Additional Use License : $845.75 |
Additional Use License. |
Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
