Key Specs


Plan Sq Ft

3290
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

4
Baths

Plan Floors

2
Floors

Plan Garages

3
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Right-Reading Reverse
$170.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design
$140.25
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List
$420.75
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide
$33.15
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design
$140.25
Receive an overlay sheet with suggested placement of lighting fixtures.
Subtotal
NOW $1355.75
You save $239.25 (15% savings)
Sale ends soon!
Best Price Guaranteed*

Also order by phone: 1-800-528-8070

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

PLAN 437-64

Plan Description


This craftsman design floor plan is 3290 sq ft and has 4 bedrooms and 4 bathrooms.

Floor Plans


Floor Plan - Main Floor

Reverse
Save

Floor Plan - Upper Floor

Reverse
Save

Full Specs & Features


Dimension

Depth : 53' 8"

Height : 35' 8"

Width : 79'

Area

Basement Unfinished: 2275 sq/ft

First Floor: 2275 sq/ft height 9'

Garage: 739 sq/ft

Second Floor: 1015 sq/ft height 9'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 12:12

Roof Framing : Truss

Roof Type : Asphalt

Secondary Pitch : 4:12

Exterior Wall Framing

Exterior Wall Finish : Brick / Siding

Framing : 2x4

Bedroom Features

Main Floor Master Bedroom

Split Bedrooms

Upstairs Bedrooms

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Great Room Living Room

Main Floor Laundry

Mud Room

Sunroom

Garage Features

Side Entry Garage

Split Garage

Lot Characteristics

Suited For Sloping Lot

Outdoor Spaces

Covered Front Porch

Screened Porch

Rooms

Bath 2:

53 sq/ft width 10' 8" x depth 5'

Bath 4:

36 sq/ft width 8' x depth 4' 6"

Bathroom 3:

88 sq/ft width 8' x depth 11'

Bedroom 2:

201 sq/ft width 14' x depth 14' 4"

Bedroom 2 Closet:

23 sq/ft width 4' 7" x depth 5'

Bedroom 3:

169 sq/ft width 13' x depth 13'

Bedroom 3 Closet:

23 sq/ft width 4' 7" x depth 5'

Bedroom 4:

178 sq/ft width 13' x depth 13' 8"

Bedroom 4 Closet:

35 sq/ft width 7' x depth 5'

Breakfast:

140 sq/ft width 12' x depth 11' 8"

Covered Front Porch:

126 sq/ft width 22' x depth 4' 6"

Dining Room:

191 sq/ft width 14' x depth 13' 8"

Foyer:

111 sq/ft width 7' 8" x depth 14' 6"

Garage 1:

470 sq/ft width 21' x depth 22'

Garage 2:

269 sq/ft width 13' x depth 20' 8"

Great Room:

330 sq/ft width 20' 10" x depth 15' 10"

Kitchen:

248 sq/ft width 16' x depth 15' 6"

Loft:

80 sq/ft width 10' 8" x depth 7' 4"

Master Bath:

171 sq/ft width 15' x depth 11' 4"

Master Bedroom:

268 sq/ft width 18' 8" x depth 14' 4"

Mud Room:

64 sq/ft width 8' x depth 8'

Pantry:

42 sq/ft width 10' x depth 4' 2"

Rear Deck:

130 sq/ft width 13' x depth 10'

Rear Screened Porch:

337 sq/ft width 33' 8" x depth 10'

Study:

182 sq/ft width 14' x depth 13'

What's Included


Please note: This designer has the following the zip code restrictions: 30041, 30501, 30504, 30506, 30542, and 30566.
