PLAN 951-1
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.Plan Description
Full Specs & Features
Height : 30' 4"
Width : 50'
Garage: 764 sq/ft height 10'
Porch: 41 sq/ft
Second Floor: 1891 sq/ft height 8' 1"
Roof Framing : Truss
Roof Type : Shingle
Framing : Wood - 2x6
Formal Dining Room
Formal Living Room / Parlor
Upstairs Master Bedrooms
Butler's Pantry
Kitchenette Wet Bar
Unfinished Future Space
Upstairs Laundry
Bedroom 2:
131 sq/ft width 10' 10" x depth 12' 2"
Bedroom 2 Closet:
14 sq/ft width 6' 10" x depth 2' 1"
Bedroom 3:
131 sq/ft width 10' 10" x depth 12' 2"
Bedroom 3 Closet:
14 sq/ft width 6' 10" x depth 2' 1"
Bedroom 4:
174 sq/ft width 13' 10" x depth 12' 7"
Bedroom 4 Closet:
17 sq/ft width 8' 2" x depth 2' 1"
Butler's Pantry:
28 sq/ft width 5' 8" x depth 5'
Coat Closet:
width 3' 10" x depth 0"
Covered Porch:
32 sq/ft width 6' 6" x depth 5'
Deck:
168 sq/ft width 14' x depth 12'
Dining Room:
147 sq/ft width 10' 10" x depth 13' 7"
Family Room:
285 sq/ft width 15' 11" x depth 17' 11"
Foyer:
74 sq/ft width 6' 6" x depth 11' 6"
Garage:
738 sq/ft width 19' 9" x depth 37' 5"
Hall Bathroom:
62 sq/ft width 12' 5" x depth 5'
Kitchen:
273 sq/ft width 13' 1" x depth 20' 11"
Kitchen Island:
21 sq/ft width 6' x depth 3' 6"
Laundry Room:
14 sq/ft width 4' x depth 3' 8"
Linen Closet:
10 sq/ft width 7' 6" x depth 1' 5"
Master Bathroom:
116 sq/ft width 12' 7" x depth 9' 3"
Master Bedroom:
302 sq/ft width 19' 5" x depth 15' 7"
Master Closet:
82 sq/ft width 11' x depth 7' 6"
Master Foyer:
24 sq/ft width 5' 10" x depth 4' 2"
Pantry:
7 sq/ft width 5' x depth 1' 5"
Parlor:
147 sq/ft width 10' 10" x depth 13' 7"
Patio:
196 sq/ft width 14' x depth 14'
Powder Room:
25 sq/ft width 5' x depth 5'
Toilet Closet:
16 sq/ft width 5' 5" x depth 3' 1"
Walk-In Closet:
82 sq/ft width 11' x depth 7' 6"
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
CAD Set : $1657.50 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
Framing
Wood 2x6: $0.00 |
Wood 2x6 |
Additional Options
Right-Reading Reverse : $148.75 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
Additional Construction Sets : $51.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
Audio Video Design : $85.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
Construction Guide : $33.15 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
Lighting Design : $170.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
Mirror Reversed Sets : $51.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
