Plan Description
This craftsman design floor plan is 2806 sq ft and has 3 bedrooms and 2.5 bathrooms.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Lower Floor
Full Specs & Features
Dimension
Depth : 78' 6"
Width : 92' 1"
Area
Bonus : 503 sq/ft
Garage : 594 sq/ft
Main Floor : 2806 sq/ft
Storage : 538 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Exterior Wall Framing
Framing : 2x6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Mud Room
Unfinished Future Space
Garage Features
Side Entry Garage
Outdoor Spaces
Screened Porch
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
» See important
information before purchasing.
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
