Plan Description

This ranch style home, with all of the grandeur of a two-story, holds universal appeal to homebuyers. Your clients will be awed by the open feeling of this plan with its two-story foyer and spacious Kitchen that opens to the Family Room. Bedroom five holds a unique appeal to each client as it can be converted to fit their individual needs, whether that be a private office for those who need to work from home, a nursery with access to the Master Suite for those who are expanding their family, an exercise room or a cozy den, whatever your clients can envision.

Floor Plans

Floor Plan - Main Floor

Reverse

House Plan Design - Mediterranean Floor Plan - Main Floor Plan #1015-18

BUILDER Advantage Program

PRO BUILDERS:

Join the club and save 5% on your first order plus exclusive discounts and more.

JOIN FOR FREE

Click to Get Your Trend Report

Floor Plan - Other Floor

Reverse

House Plan Design - Mediterranean Floor Plan - Other Floor Plan #1015-18

Full Specs & Features

Dimension

Depth : 65' 8"
Height : 22' 4"
Width : 60'

Area

First Floor: 2789 sq/ft
Garage: 418 sq/ft
Storage: 33 sq/ft

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12
Roof Framing : Truss
Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Stucco
Framing : Block

Bedroom Features

Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Walk In Closet

Kitchen Features

Kitchen Island
Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room
Main Floor Laundry

Outdoor Spaces

Covered Front Porch
Covered Rear Porch

Rooms

Bedroom 2:

128 sq/ft width 11' 8" x depth 11'

Bedroom 3:

128 sq/ft width 11' 8" x depth 11'

Bedroom 4:

128 sq/ft width 11' 8" x depth 11'

Bedroom 5:

176 sq/ft width 12' x depth 14' 8"

Bedroom/Bonus Room:

266 sq/ft width 14' x depth 19'

Breakfast Room:

60 sq/ft width 9' 6" x depth 6' 4"

Dining Room:

147 sq/ft width 11' 8" x depth 12' 8"

Family Room:

323 sq/ft width 18' 4" x depth 17' 8"

Garage:

383 sq/ft width 20' x depth 19' 2"

Kitchen:

200 sq/ft width 14' 8" x depth 13' 8"

Laundry Room:

41 sq/ft width 7' 2" x depth 5' 10"

Living Room:

134 sq/ft width 12' x depth 11' 2"

Master Bathroom:

122 sq/ft width 16' 8" x depth 7' 4"

Master Bedroom:

293 sq/ft width 13' 4" x depth 22'

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
