Depth : 47'
Height : 30' 6"
Width : 57' 8"
Basement : 1439 sq/ft
Garage : 461 sq/ft
Main Floor : 1439 sq/ft
Porch : 182 sq/ft
Upper Floor : 1206 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling Details : Master Bedroom ceiling vaults to 9'
Garage Ceiling : 10' 5"
Main Ceiling : 9' 1"
Upper Ceiling Ft : 8' 1"
Primary Pitch : 8:12
Roof Framing : Truss
Roof Load : 47 psf
Roof Type : Shingle
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick & Siding
Framing : 2 x 4
Insulation : R 15
Upstairs Master Bedrooms
Walk In Closet
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Main Floor Laundry
