PLAN 927-783
Key Specs
2396
sq ft
4
Beds
2.5
Baths
2
Floors
2
Garages
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.Plan Description
Brick and shake create a weathered look for this Colonial home, complemented by a pediment entry; use recycled materials for more vintage appeal. A two-story foyer is graced with French doors to the living room/study. A two-story family room is enhanced by radius windows and a warming fireplace. The serving-bar kitchen is conveniently central to the bayed breakfast nook and formal dining room. Upstairs, three family bedrooms (one lit by dormer windows) share a full bath. The master suite resides in luxury with a sumptuous private bath that includes a vaulted ceiling and corner tub. The garage in the photo has been changed from the plan to open to the side.
Special offer for builders! Select a CAD, PDF, or Reproducible format, and you will receive an unlimited use license at no additional cost. Build as many times as you like with no re-use fees! This offer only applies to plans bearing this note. Unless explicitly noted, a purchased plan may only be built once. An unlimited use license is not transferable.
Special offer for builders! Select a CAD, PDF, or Reproducible format, and you will receive an unlimited use license at no additional cost. Build as many times as you like with no re-use fees! This offer only applies to plans bearing this note. Unless explicitly noted, a purchased plan may only be built once. An unlimited use license is not transferable.
Full Specs & Features
Dimension
Depth : 47' 6"
Height : 32' 3"
Width : 50'
Height : 32' 3"
Width : 50'
Area
Basement Unfinished: 1186 sq/ft
First Floor: 1186 sq/ft height 9'
Garage: 503 sq/ft
Second Floor: 1210 sq/ft
First Floor: 1186 sq/ft height 9'
Garage: 503 sq/ft
Second Floor: 1210 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Dining Room
Kitchen Features
Breakfast Nook
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Main Floor Laundry
Outdoor Spaces
Covered Front Porch
Rooms
Bedroom 2:
width 12' x depth 11'
Bedroom 3:
width 11' x depth 11' 2"
Bedroom 4:
width 11' x depth 11' 2"
Breakfast Nook:
width 11' x depth 13'
Dining:
width 11' x depth 13' 6"
Foyer:
width 6' 10" x depth 9' 8"
Garage:
width 19' 9" x depth 21' 9"
Great Room:
width 18' x depth 15'
Kitchen:
width 11' x depth 11' 6"
Laundry:
width 6' x depth 6'
Living Room:
width 11' x depth 13' 6"
Master Bathroom:
width 13' 9" x depth 12'
Master Bedroom:
width 17' x depth 13' 4"
Master Closet:
width 6' 2" x depth 8' 8"
What's Included In This Plan Set
- Purchasing a CAD set, PDF set, or Reproducible set, gives you an unlimited build license. All other plan sets, allow you to build the home one time.
- All plans include the front elevation at 1/4" or 3/16" and the sides and rear elevations at 1/8" scale. These elevations show and note the exterior finished materials of the house.
- Every plan is available with a walkout style basement (three masonry walls and one wood framed rear wall with windows and doors). The basement plans are a 1/4" or 3/16" scale layout of unfinished spaces showing only the necessary 2 x 6 wood framed load bearing walls. These plans are completed with dimensions, notes, and door/window sizes. Crawl space and/or slab on grade foundations are available for some plans. All foundation types are not available for all plans.
- Each plan consists of 1/4" or 3/16" scale floor layouts showing the location of 2x4 walls, doors, windows, plumbing fixtures, cabinetry, stairs and decorative ceilings. These plans are complete with dimensions, notes, door/window sizes and a schematic electrical layout.
- The building sections are drawings which take vertical cuts through the house and the stairs showing floor, ceiling and roof height information.
- The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer. Details are included for many interior and exterior conditions to provide more specific information for their construction.
- Each floor framing plan shows each floor joist indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Each framing plan sheet includes any framing details that are needed (tray details, connection details, etc.). All of the framing is designed using conventional 2 X 10 floor joist or wood I-Joist, depending on the span conditions of each home plan. Framing plans are not available for all home plans.
- The ceiling joist framing plan shows each ceiling joist indicating the size,spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- The roof framing plan shows each rafter, valley, hip and ridge indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- Each plan order includes one set of typical detail sheets that show foundation details, typical wall sections and other framing details. Also included on the detail sheets are miscellaneous interior trim and fireplace details that can be used to customize the home.
