Key Specs
2239
sq ft
4
Beds
3
Baths
1
Floors
3
Garages
This plan can be customized!
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing.Need a quote fast? Call us at 1-800-528-8070.
Plan Description
With both an island and a separate bar, this kitchen gives you tons of counter space for cooking, baking, and simply hanging out with family and friends. Other special details in the home include decorative ceiling treatments throughout (including a tray ceiling in the luxurious master suite), a versatile study/bedroom 4 bear the front, and lots of storage (like the big pantry near the three-car garage).
Floor Plans
Floor Plan - Main Floor Plan
Floor Plan - Other Floor Plan
Floor Plan - Other Floor Plan
Full Specs & Features
Dimension
Depth : 81' 6"
Height : 26' 10"
Width : 69'
Height : 26' 10"
Width : 69'
Area
Bonus: 566 sq/ft
First Floor: 2239 sq/ft height 10'
Garage: 830 sq/ft
Porch: 559 sq/ft
First Floor: 2239 sq/ft height 10'
Garage: 830 sq/ft
Porch: 559 sq/ft
Ceiling
Ceiling Details : Coffered Great Room ceiling, Tray ceiling in Dining Area and Master Bedroom
Main Ceiling : 10'
Main Ceiling : 10'
Roof
Primary Pitch : 8/12
Roof Framing : Conventional
Roof Type : Asphalt
Secondary Pitch : 8/12
Roof Framing : Conventional
Roof Type : Asphalt
Secondary Pitch : 8/12
Exterior Wall Framing
Exterior Wall Finish : Shingle & Siding
Framing : 2 X 4
Framing : 2 X 4
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Play Flex Room
Storage Area
Sunroom
Unfinished Future Space
Great Room Living Room
Main Floor Laundry
Play Flex Room
Storage Area
Sunroom
Unfinished Future Space
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Screened Porch
Covered Rear Porch
Screened Porch
More
Empty Nester
Rooms
Covered Front Porch:
222 sq/ft
Covered Rear Porch:
110 sq/ft
Covered Side Porch:
46 sq/ft
Screened Porch:
181 sq/ft
