Plan Description

Cozy: An extra master suite on the main floor gives you tons of versatility in this home. In-laws or visitors will appreciate the comfort and accessibility of the second master suite, which features a contemporary large shower, two sinks, and a walk-in closet. Owners get to relax in the even-larger master suite across the home. The open layout of the gathering spaces encourages mingling, especially around the kitchen’s island and the cozy fireplace in the great room. Just 42 feet wide, the narrow footprint fits a tight lot. Two additional bedrooms upstairs each feature a walk-in closet and easy access to the big bonus space. Don’t miss the handy drop zone on the way in from the garage.

Floor Plans

Floor Plan - Main Floor

Reverse

House Plan Design - Craftsman Floor Plan - Main Floor Plan #20-2254

BUILDER Advantage Program

PRO BUILDERS:

Join the club and save 5% on your first order plus exclusive discounts and more.

JOIN FOR FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

House Plan Design - Craftsman Floor Plan - Upper Floor Plan #20-2254

Full Specs & Features

Dimension

Depth : 54'
Height : 28' 8"
Width : 42'

Area

Bonus: 248 sq/ft
First Floor: 1584 sq/ft height 9'
Garage: 512 sq/ft
Second Floor: 532 sq/ft height 8'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Ceiling Details : Sloped ceiling in Great Room & Dining area, 10' tray ceiling in Master Bedroom
Lower Ceiling : 9'
Main Ceiling : 9'
Upper Ceiling Ft : 8'

Roof

Primary Pitch : 9:12
Roof Framing : Conventional
Roof Type : Shingle
Secondary Pitch : 9:12

Exterior Wall Framing

Exterior Wall Finish : Brick/shingle/siding
Framing : 2 x 6

Bedroom Features

Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet

Kitchen Features

Eating Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Great Room Living Room
Main Floor Laundry
Mud Room
Unfinished Future Space

Garage Features

Front Entry Garage

Outdoor Spaces

Covered Front Porch
Covered Rear Porch
