Depth : 28' 8"
Height : 24' 3"
Width : 40' 4"
First Floor: 1056 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof Framing : Conventional
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x6 Wood - 2x4
Formal Living Room / Parlor
Main Floor Master Bedroom
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Open Floor Plan
Vaulted / Cathedral Ceilings
