Plan Description

This modern house is designed in structural wood, uses certified eco-friendly materials that allow healthy internal micro-climatic conditions. Its architecture is energy-saving: with the correct orientation on the construction lot, the house allows solar gain during winter, whilst shielding the excessive heat in summer, also due to the presence of the front porch. The large glass 'solar control' wall panels, provide excellent insulating, self-cleaning and safety characteristics. The side-walls form a continuous sheathing with the cover, to give the house greater thermal and acoustic insulation. The interiors, which have a full-height development, are open-space with kitchen, living and dining. The sleeping area is a separate private location. The house can be equipped with renewable energy systems such as solar thermal, photovoltaic and mini-wind turbines. The attention paid in the preliminary design stage is on the use of materials, the shape and orientation of the house which assures an optimum quality for money ratio both in its maintenance and energy-management.

Floor Plans

Floor Plan - Other Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Main Floor

Reverse

Full Specs & Features

Dimension

Depth : 43' 8"

Height : 18' 4"

Width : 73'

Area

Garage : 392 sq/ft

Main Floor : 1681 sq/ft

Patios : 285 sq/ft

Porch : 226 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 11' 6"

Main Ceiling : 17'

Roof

Roof Framing : Wooden structure

Exterior Wall Framing

Exterior Wall Finish : wood/tiles

Framing : Wooden structure

Insulation : Eco-friendly mineral wool/wood fibre panel

Bedroom Features

Main Floor Bedrooms

Main Floor Master Bedroom

Additional Room Features

Den Office Study Computer

Great Room Living Room

Main Floor Laundry

Garage Features

Carport Porte Cochere

Side Entry Garage

Entryway

Friend S Entry

Lot Characteristics

Suited For View Lot

Outdoor Spaces

Courtyard

Economical To Build

Unusual Shape

Wheelchair Adaptable

Energy Efficient Features

Energy Efficient Design

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
