Depth : 62'
Height : 21'
Width : 36'
Main Floor : 1485 sq/ft
Porch : 480 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Primary Pitch : 7:12
Roof Framing : Truss
Exterior Wall Framing
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Suited For Corner Lot
Suited For Narrow Lot
Suited For View Lot
Covered Front Porch
Covered Rear Porch
Economical To Build
Suited For Vacation Home
