PLAN 124-942

Plan Description


This traditional 2 car garage plan has two separate garage doors that are both 9' wide and 8' tall. To the left is a studio which features a full kitchen and bathroom along with a walk-in closet.

Full Specs & Features


Dimension

Depth : 34'

Height : 18' 4"

Width : 46'

Area

Garage : 660 sq/ft

Main Floor : 615 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'

Roof

Primary Pitch : 8/12

Roof Framing : Truss/Stick

Roof Load : 25

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : 2x6

Bedroom Features

Main Floor Bedrooms

Walk In Closet

Additional Room Features

Great Room Living Room

Garage Features

Front Entry Garage

What's Included


Please note, if ordering a PDF Print Set, it is not-modifiable. The CAD set is best for making local modifications. The "5 set + PDF" combo contains a non-modifiable PDF Print Set. The "8 set + PDF" combo contains a non-modifiable PDF Print Set.

Each plan set is drawn at 1/4"=1' scale and includes the following drawings:
