Plan Description
This country design floor plan is 1092 sq ft and has 2 bedrooms and 2 bathrooms.
Floor Plans
Floor Plan - Lower Floor
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 50'
Height : 26'
Width : 36'
Area
Lower Floor : 108 sq/ft
Main Floor : 984 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Lower Ceiling : 9'
Main Ceiling : 11'
Roof
Primary Pitch : 4:12
Secondary Pitch : 10:12
Exterior Wall Framing
Framing : 2"x6"
Bedroom Features
Upstairs Bedrooms
Walk In Closet
Additional Room Features
Great Room Living Room
Storage Area
Upstairs Laundry
Garage Features
Front Entry Garage
Garage Under
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
