Full Specs & Features
Height : 38'
Width : 116' 10"
Second Floor: 1667 sq/ft
Main Ceiling : 10'
Upper Ceiling Ft : 9'
Roof Framing : Conventional
Roof Load : 45
Roof Type : Shingle
Framing : 2x4
Insulation : R-13
Main Floor Master Bedroom
Upstairs Bedrooms
Walk In Closet
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Mud Room
Workshop
Rear Garage
Side Entry Garage
Covered Rear Porch
Outdoor Kitchen Grill
Bath 2:
width 5' x depth 8'
Bath 3:
width 5' 2" x depth 12'
Bath 4:
width 11' x depth 5'
Bedroom 2:
width 14' 4" x depth 12'
Bedroom 3:
width 16' x depth 12'
Bedroom 4:
width 14' 4" x depth 15' 8"
Closet:
width 17' x depth 9' 6"
Exercise Room:
width 20' x depth 12'
Foyer:
width 11' x depth 17'
Game/Media Room:
width 18' 4" x depth 16' 8"
Great Room:
width 19' 4" x depth 18' 10"
Hearth Room/Dining:
width 17' 10" x depth 12'
Kid's TV Room:
width 18' 4" x depth 13'
Kitchen:
width 17' 10" x depth 17'
Laundry Room:
width 13' 8" x depth 12' 9"
Lawn Storage:
width 8' x depth 11' 6"
Master Bath:
width 12' 8" x depth 15' 8"
Master Suite:
width 17' x depth 18'
Porte Cochere:
width 20' x depth 21' 4"
Rear Covered Outdoor Living:
693 sq/ft width 20' 9" x depth 19' 4"
Storage/Safe Room:
width 7' 4" x depth 11' 6"
Three Car Garage:
width 34' 8" x depth 24'
Workshop/Garage 2:
width 27' 4" x depth 23' 8"
Floor Plan - Main Floor
Floor Plan - Upper Floor
In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.
To find out what documents you should expect with your house plans, see /help/faq#faq13.
In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.
Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
